- Product Size
- Technical Specification
| （UL-P-1014-0100-A-G LED-1） WL-P-1014-0100-A-G LED-1 | ||
| 1 | LED Type and Quantity | 1*1W CREE CXA1304 |
| 2 | LED quantity in series connection*in-parallel connection | 1*1 |
| 3 | LED BIN | VF=(6.0~6.2)V |
| 4 | CCT & CRI | 2700K/3000K/4000K/6000K Ra≥80 |
| 5 | SDCM | < 6 steps |
| 6 | Current for all LED | 0.1A(DC24V) |
| 7 | Current for each pc LED | 0.15A |
| Electricalelectronic | ||
| 1 | Rated Input Voltage & Frequency | DC24V |
| 2 | System Power | 1.2W±10% |
| 3 | Control/Dimming | ONOFF PWM |
| Optical | ||
| 1 | System Lumen Package(typical) | 80~85 lm |
| 2 | System Efficacy(typical)lm/w | 70 LM/W |
| 3 | Beam Angle | 120° |
| Mechanical & packaging for front cover | ||
| 1 | Luminaire Size (L*W*H) | Ø49×10.4 (mm) Diameter x length |
| 2 | Weight per piece | 0.023 kgs |
| 3 | Packaging quantity | 100 |
| 4 | Packaging size | 32.5*23.5*17cm |
| 5 | Gross weight KG) | 3.3KG |
| Material & Finishing | ||
| 1 | Luminaire Body material & color | Aluminum |
| 2 | Material for Lens or Reflector | PMMA |
| 3 | in conformity with Rohs or not? | Yes |
| 4 | External cable size and length | PVC 0.3m 2×0.3mm2 |
| 5 | Mounting Sleeve/ Spike/ Others | Screws |
| Mounting | ||
| 1 | Surface/Recessed/Suspended/… | Surface installation |
| Classification | ||
| 1 | Approbation | CE |
| 2 | IP | IP67 |
| 3 | IK | IK06 |
| 4 | Lum Classification | III |
| 5 | Working temp | -40℃～70℃ |
| 6 | Life time in hours | 50000h |
| 7 | Warranty years | 3 |
- Selling Point:
1) Can be used as Inground Light, Wall Light and Deck Light.
2) Osram LED chip.
3) Front cover: Flush anodized aluminum 6063 cover.
4) Housing: Solid Passivated 6063 aluminum
5) Power cable: PVC cable 2×0.3mm2, length is 0.3 meters
6) Driver: Constant current output, Rubycon cap, can be used under very low temperature.
7) Operating temperature: -20 to 60 ℃
8) IP Rating: IP67
9) Warranty: 3 years
- Light Distribution Curve
- Illuminance Distance Curve
- Light Application
